Sluice Gates

Design Features *

- It is a sluice gate made of high density polyethylene(HIGH DENSITY POLYETHYLENE).
- It is very resistant to corrosion and is light in weight so there is little force used to open and close the sluice gate and it is easy to lift and handle.
- It is easy to install and has excellent watertightness.
- Compared to the cast iron sluice gate, It has stronger corrosion resistance against salt, sewage and bad products.
- It’s light weight makes it easy to install and operate when opening and closing.
- The watertightness of the seat can be guaranteed by simple operation by the seat adjustment bolt.
- It prevents the shaking of the gate by running water during opening and closing of the sluice gate.

Sluice Gate Specification *

Size Range

Ø200~Ø2900 mm
Large diameter over 2000 can be manufactured according to customer’s request

Workimg Pressure

0.98 MPa(10 kg/cm2)

Fluids

Water supply & Sewage

Materials

- GATE: HDPE(HIGH DENSITY POLYETHYLENE)
- SUPPORT RIB: STS 304
- SEAL: EPDM
- GUIDE FRAME: STS 304
Other materials can also be applied according to customer requirements.
